MEXE02 Support Software, v3.71

Last Updated on: 12/15/2021

*Windows 8 - 10, please contact Technical Support for older versions

MEXE02 Support Software for Standard Products,
for Ethernet/IP™ or EtherCAT products please refer to appropriate tab.

Cable for connection to PC required for data setting software (CC05IF-USB)

**Standard USB communications cable (not supplied) required for AZ Series products.

• Create motion profiles and execute them immediately
• Full system configurability
• I/O monitoring
• Waveform capture
• Drag and drop programming capability
• Upload/Download programs and parameters
• Built-in terminal function
• Linked motion creator

Applicable Products

Brushless DC Motors

Series	Product Type	Communication Table Type
BLE2 series	-	USB cable
BLE series	Standard type/Type with electromagnetic brake	CC05IF-USB
	CC-Link Ver.1.1 compatible
	RS-485 communication type
BXⅡ series	Position control mode
	Speed ​​control mode
BLH series	Digital setting type	USB cable
	RS-485 communication type
BLV series	Standard type/Type with electromagnetic brake	CC05IF-USB



αSTEP Closed Loop Stepper Motors

Series	Product Type	Communication Table Type
AR series	Pulse input type	CC05IF-USB
	Built-in positioning function type
	DeviceNet compatible



Stepper Motors

Series	Product Type	Communication Table Type
RKⅡ series	Built-in positioning function type	CC05IF-USB
CRK series	Built-in positioning function type
PKA series	Built-in positioning function type



Servo Motors

Series name	Communication cable
NX series	CC05IF-USB



Linear Actuators

Series	Product Type	Communication Table Type
Equipped with EAS series α STEP AR series	Pulse input type	CC05IF-USB
	Built-in positioning function type
EZS series Clean room compatible αSTEP AR series installed	Pulse input type	CC05IF-USB
	Built-in positioning function type
EZSH series α STEP AR series installed	Pulse input type	CC05IF-USB
	Built-in positioning function type
EAC series α STEP AR series installed	Pulse input type	CC05IF-USB
	Built-in positioning function type
DRLⅡ series	Built-in positioning function type	CC05IF-USB



Hollow Rotary Acutators

Series	Product Type	Communication Table Type
DGⅡ seriesα STEP AR series installed	Pulse input type	CC05IF-USB
	Built-in positioning function type
DGⅡ seriesRKⅡ series installed	Built-in positioning function type	CC05IF-USB



Network Converters

Product Type	Communication cable
CC-Link Ver.2 compatible	USB cable
CC-Link Ver.1.1 compatible	CC05IF-USB
MECHATROLINK-II compatible
MECHATROLINK-Ⅲ compatible
EtherCAT compatible

Support Software for Network AZ Series Compatible Drivers

v4.70

Last Updated on: 12/15/2021

*Windows 8 - 10, please contact Technical Support for older versions

Support software for use with Network AZ Series Drivers.

EtherNet/IP™ EDS File for AZ Series Compatible Drivers

Rev1.00

Last Updated on: 3/2/2020

An EDS file has been prepared to allow EtherNet/IP™ compatible products to be used more easily.



Add-On Instructions (AOI) for AZ Series EtherNet/IP™ Compatible Drivers

Rev1.3 U1.0

Last Updated on: 3/16/2020

Add-On Instructions (AOI) for AZ Series EtherNet/IP driver. Use the AOI to save programming time or make it easier to read or write your data parameters in AZ Series driver.

• Move Command
• Operation Position / Speed
• Current Settings or Accel/Decel Settings
• Monitoring
• Direct Data Operation (changing data on the fly)
• AOI User Guide for AZ Series Included



ESI File for AZ Series EtherCAT Drivers

The ESI File for the AZ Series EtherCAT driver is available for download. For the AZ Series Multi-Axis installation and connection information, see the operator's manual.

ESI File for NETC01-ECT Network Converter (EtherCAT)

The ESI File for the NETC01-ECT EtherCAT gateway converter is available for download. For the NETC01-ECT installation and connection information, see the operator's manual.

ESI File for AZ Series Multi-Axis Controller / Driver (EtherCAT)

Rev3.01

The ESI File for the AZ Series Multi-Axis EtherCAT controller is available for download. For the AZ Series Multi-Axis installation and connection information, see the operator's manual.

PROFINET GSD File for AZ Series Compatible Drivers

Rev2.4

Last Updated on: 7/1/2021

An GSD file has been prepared to allow PROFINET compatible products to be used more easily.



Applicable Products

αSTEP Closed Loop Stepper Motors

Series	Product Type	Communication Table Type
AZ series	Built-in positioning function type	USB cable
	Small driver
AZ series multi-axis driver	EtherCAT drive profile support
	MECHATROLINK-Ⅲ compatible
	SSCNET III/H compatible



Linear Actuators

Series	Product Type	Communication Table Type
Equipped with EAS series α STEP AZ series	Built-in positioning function type	USB cable
EZS series α STEP AZ series installed	Built-in positioning function type	USB cable
EZS series Clean room compatible αSTEP AZ series installed	Built-in positioning function type	USB cable
EZSH series α STEP AZ series installed	Built-in positioning function type	USB cable
EAC series α STEP AZ series installed	Built-in positioning function type	USB cable
DR series α STEP AZ series installed	Built-in positioning function type	USB cable
DRS2 series α STEP AZ series installed	Built-in positioning function type	USB cable
Equipped with L series α STEP AZ series	Built-in positioning function type	USB cable
EH series α STEP AZ series installed	Built-in positioning function type	USB cable



Hollow Rotary Acutators

Series	Product Type	Communication Table Type
DGⅡ seriesα STEP AZ series installed	Built-in positioning function type	USB cable

Support Software for CVD RS-485 Communiction Type Drivers

v4.70

Last Updated on: 12/15/2021

*Windows 8 - 10, please contact Technical Support for older versions

Support software for use with CVD RS-485 Communication Type Drivers.





BLST01 Support Software for BLVD-KRD Drivers

v2.01

*Windows 10

By using the Support Software BLST01, data setting, actual operation, and confirmation via each monitor can be performed easily on a computer.



Fuji Electric FRENIC Loader Software for Inverters / VFD



CRK Stored Program Controller (CRK5xx-KP) Motion Creator Software, v2.02

Last Updated on: 7/10/2012

• Create motion profiles and execute them immediately
• Full system configurability
• I/O monitoring
• Multi-axis control
• Waveform capture
• Drag and drop programming capability
• Upload/Download programs and parameters
• Built-in terminal function
• Linked motion creator
